SFT-T1M 1000Base-T1 Gigabit Coaxial to RJ45 Master Device
Model Number: SFT-T1M
Brand: Softel
MOQ: 1
1 bidirectional gigabit coaxial transmission port
Integrating gigabit coaxial to gigabit RJ45 conversion
Support 100Mbps/1G adaptive
01
Product Description
Introduction
SFT-T1M type master device is a 1000Base- T1 main-end product designed to meet the requirements of different operators for gigabit coaxial to RJ45 conversion . This model is mature, stable, and cost-effective, integrating gigabit Ethernet switching technology and gigabit coaxial transmission technology. It has the characteristics of high bandwidth, high reliability, and easy installation and maintenance.
These series products can solve problems such as time-consuming and labor-intensive household construction, achieve instant installation and connectivity of high bandwidth services, and improve the efficiency of bidirectional operation and customer satisfaction across the entire network. It can also solve problems such as fiber optic cables not being able to enter households or difficult construction, and achieve gigabit bandwidth access based on coaxial technology, effectively improving the bidirectional access rate of the entire network.
Key Features
Supports 1 bidirectional gigabit coaxial transmission port
Supports 100Mbps/1G adaptive, supports coaxial interface bidirectional feeding
| Item | Parameter | Specification |
| T1 interface | C | |
| Supports bidirectional feeding of coaxial cable | ||
| Supports coaxial transmission over 80 meters via Gigabit network | ||
| LAN interface | 1*1000M Ethernet port | |
| Full duplex/half duplex | ||
| RJ45 port ，Support cross direct connection self-adaptation | ||
| Transmission distance 100 meters | ||
| Power interface | +12VDC power interface | |
| Performance specifications | Data transmission performance | |
| Ethernet port： 1000Mbps | ||
| Packet loss rate：<1*10E-12 | ||
| Transmission delay：<1.5ms | ||
| Physical characteristics | Shell | ABS engineering plastics shell |
| Power supply and consumption | External 12V/0.5A~ 1.5A power adapter (Optional) | |
| Consumption：<3W | ||
| Dimension and weight | Dimension ：104mm(L) ×85mm(W) ×25mm (H) | |
| Weight：0.2kg | ||
| Environmental parameters | Working temperature：0～45℃ | |
| Storage temperature：-40～85℃ | ||
| Working humidity：10%～90% non-condensation | ||
| Storage humidity：5%～95% non-condensation |
| Number | Mark | Description |
| 1 | RUN | Operating status indicator light |
| 2 | LAN | Gigabit Ethernet port RJ45 |
| 3 | 12VDC | DC 12V power input interface |
| 4 | PON | 1*GE coaxial F-type port(Metric/Imperial optional) |
| 5 | RF | Gigabit coaxial F type port |
| Identification | Status | Definition |
| RUN | Flashing | POWER ON and normal operation |
| OFF | POWER OFF or abnormal operation | |
| T1 | ON | GE Coaxial interface is connected |
| Flashing | GE Coaxial data is transmission | |
| OFF | GE Coaxial interface is not in use |
Note
(1) 1000Base-T1 series products are used in a one-to-one mode.(One master and one slave are used in conjunction)
(2) The product models are divided into two specifications: -M (master) and -S (slave).
(3) The appearance structure of the master and slave devices is the same, and they are distinguished by model labels.
