1550nm WDM EDFA 16 Ports Fiber Amplifier for XPON Network
Model Number: SPA-16-XX
Brand: Softel
MOQ: 1
One-key down 6dBm for Maintenance
Adopts JDSU or Oclaro Pump Laser
Dual Power Hot-plug Power Supply of 90V～250V AC or -48V DC
01
Product Description
Functional Features
1. Single/dual input for choice, built-in optical switch for dual input, the switching power can be set by the button in the front panel or by web SNMP.
2. Output adjustable by buttons in the front panel or web SNMP, the range is down 4dBm
3. Maintenance function of one-time downward attenuation of 6dBm by buttons in the front panel or web SNMP, to facilitate the optical fiber hot-plug operation without turning off the device
4. Multi- ports output, can be built in 1310/1490/1550nm WDM.
5. Standard RJ 45 port for remote control, we can provide an output contract and web manager for choice, and also plug-in SNMP hardware can be reserved for the update.
6. With laser key to turn on/off the laser.
7. With RF test function.
8. Adopts JDSU or Oclaro Pump laser
9. Led displays the working condition of the machine
10. Dual power hot plug power supply for choice, 90V～250V AC or -48V DC
Application:
1. FTTH, FTTB, EPON, GPON, XG(S)-PON, etc.
2. Make full use of existing optical fiber resources to achieve network upgrades and capacity expansion.
3. IP QAM narrow insert data service.
|
SPA-16-XX 1550nm WDM EDFA 16 Ports Fiber Amplifier |
||||||||||
|
Items |
Parameter |
|||||||||
| Output（dBm） |
31 |
32 |
33 |
34 |
35 |
36 |
37 |
38 |
39 |
40 |
| Output（mW） |
1250 |
1600 |
2000 |
2500 |
3200 |
4000 |
5000 |
6400 |
8000 |
10000 |
| Input(dBm) |
-8～+10 |
|||||||||
| Range of output adjustment (dBm) |
Down 4 |
|||||||||
| one-time downward attenuation(dBm) |
Down 6 |
|||||||||
| Wavelength （nm） |
1540～1565 |
|||||||||
| Output stability(dB) |
<±0.3 |
|||||||||
| Optical Return Loss（dB） |
≥45 |
|||||||||
| Fiber Connector |
FC/APC、SC/APC、SC/IUPC、LC/APC、LC/UPC |
|||||||||
| Noise Figure （dB） |
<6.0(input 0dBm) |
|||||||||
| Web port |
RJ45(SNMP) |
|||||||||
| Power Consumption （W） |
≤80 |
|||||||||
| Voltage （V） |
220VAC(90～265)、-48VDC |
|||||||||
| Working Temp（℃） |
-0～55 |
|||||||||
| Size （mm） |
370(L)×486(W)×88(H) |
|||||||||
| NW（Kg） |
8 |
|||||||||
