2.4GHz & 5GHz Dual Band 1.5 Gbps 4*LAN Ports Wi-Fi 6 Router
Model Number: SWR-4GE15W6
Brand: Softel
MOQ: 1
2.4GHz & 5GHz Dual Band, Speed up to 1500Mbps
WiFi6 Gig+ Performance, WPA3 Encryption
Extended 5*Antennas, Wide Coverage
01
Product Description
SWR-4GE15W6 is a gigabit Wi-Fi 6 Router designed for home users， which rates up to 1501Mbps (2.4GHz: 300Mbps, 5GHz: 1201Mbps). SWR-4GE15W6 is equipped with high-performance FEMs and 5 external 6dBi high-gain antennas. More devices can be connected to the internet at the same time with lower lag, and the transmission efficiency is significantly improved by OFDMA+MU-MIMO technology. Connecting more wired devices for faster transfer speed with the gigabit ethernet port, make sure all kinds of wired devices work smoothly then enjoy the ultra-speed network.
| 2.4GHz & 5GHz Dual Band 1.5 Gbps 4*LAN Ports Wi-Fi 6 Router | |
| Hardware Parameter | |
| Size | 239mm*144mm*40mm(L*W*H) |
| Wired standard | IEEE802.3, IEEE802.3u, IEEE802.3ab |
| Interface | 4*GE(1*WAN+3*LAN, RJ45) |
| Antenna | 5*6dBi, External omnidirectional antenna |
| Button | WPS/Reset |
| Power adapter | Input: AC 100-240V, 50/60Hz |
| Output: DC 12V/1A | |
| Working environment | Working temperature: 0 ℃ ~ 40℃ |
| Working humidity: 10% ~ 90% RH (Non condensing) | |
| Storage environment | Storage temperature: -40 ℃ ~ 70 ℃ |
| Storage humidity: 5% ~ 90% RH (Non condensing) | |
| Indicators | LED*1 |
| Wireless Parameter | |
| Wireless standard | 5GHz: IEEE 802.11 ax/ac/a/n |
| 2.4GHz: IEEE 802.11 b/g/n | |
| Wireless spectrum | 2.4GHz & 5GHz |
| Wireless rate | 2.4GHz: 300Mbps |
| 5GHz: 1201Mbps | |
| Wireless function | Support OFDMA |
| Support MU-MIMO | |
| Support Beamforming | |
| Wireless encryption | WPA2-PSK, WPA3-SAE/WPA2-PSK |
| Wireless encryption disable and enable | |
| WPS fast and secure connection | |
| Software Data | |
| Internet access | PPPoE, Dynamic IP, Static IP |
| IP protocol | IPv4 & IPv6 |
| Working mode | AP mode |
| Wireless routing mode | |
| Wireless relay mode(Client+AP, WISP) | |
| Access control | Client filtering |
| Parental control | |
| Firewall | Anti WAN port PING, disabled/enabled |
| Anti UDP packet flooding | |
| Anti TCP packet flooding | |
| Anti ICMP packet flooding | |
| Virtual server | UPnP |
| Port forwarding | |
| DMZ host | |
| DHCP | DHCP server |
| DHCP client list | |
| DHCP static address reservation and allocation | |
| Others | IPTV |
| IPv6 | |
| Dual frequency integration function | |
| Intelligent power saving | |
| Bandwidth control | |
| Guest network | |
| System log | |
| Remote Web management | |
| MAC Address Clone | |
| Automatic migration technology of broadband account | |
| Configure backup and recovery | |
| Support automatic detection of access mode | |
| Online upgrade (New version push and online detection) | |
| Network status display | |
| Network topology | |
WiFi6 Router_SWR-4GE15W6 Datasheet-V1.0 EN
