4*GE(1*WAN+3*LAN)Speed up to 1.8Gbps Gigabit Wi-Fi 6 Router
Model Number: SWR-4GE18W6
Brand: Softel
MOQ: 1
2.4GHz & 5GHz Dual Band; Speed up to 1.8Gbps
WPA3 Encryption; Strengthen Network Security
4*5dBi Antennas and Mesh Networking
SWR-4GE18W6 is a Gigabit Wi-Fi 6 router specially designed for home users. It is equipped with 4 external 5dBi high-gain antennas, more devices can be connected to the router at the same time to surf the Internet with lower latency. It supports OFDMA+MU-MIMO technology, which can significantly improve data transmission efficiency, and its wireless rate is as high as 1800Mbps (2.4GHz: 573.5Mbps, 5GHz: 1201Mbps).
SWR-4GE18W6 supports WPA3 WIFI encryption, which can ensure the security of users’ online data. This router has 4 Gigabit Ethernet ports, which can be connected to multiple Internet devices (such as computers, NAS, etc.) through network cables to ensure the smooth operation of various wired devices and enjoy ultra-high-speed Internet.
| SWR-4GE18W6 4*GE 1.8Gbps Gigabit Wi-Fi 6 Router | |
| Hardware Parameter | |
| Size | 157mm*157mm*33mm(L*W*H) |
| Interface | 4*GE(1*WAN+3*LAN, RJ45) |
| Antenna | 4*5dBi, External omnidirectional antenna |
| Button | 2: RST key + (WPS/MESH combination key) |
| Power adapter | Power input: DC 12V/1A |
| Power consumption: <12W | |
| Working environment | Working temperature: -5 ℃ ~ 40℃ |
| Working humidity: 0 ~ 95%(Non-condensing) | |
| Storage environment | Storage temperature: -40 ℃ ~ 85 ℃ |
| Storage humidity: 0 ~ 95%(Non-condensing) | |
| Indicators | 4 LED Indicators: Power supply, WAN Two-color signal light, WIFI light, MESH light |
| Wireless Parameters | |
| Wireless standard | IEEE 802.11 a/b/g/n/ac/ax |
| Wireless spectrum | 2.4GHz & 5.8GHz |
| Wireless rate | 2.4GHz: 573.5Mbps |
| 5.8GHz: 1201Mbps | |
| Wireless encryption | WPA, WPA2, WPA/WPA2, WPA3, WPA2/WPA3 |
| Wireless antenna | 2*WIFI 2.4G antenna+2*WIFI 5G antenna MIMO |
| 5dBi/2.4G; 5dBi/5G | |
| Wireless output power | 16dBm/2.4G; 18dBm/5G |
| Wireless support bandwidth | 20MHz, 40MHz, 80MHz |
| Wireless user connections | 2.4G: 32 users |
| 5.8G: 32 users | |
| Wireless function | Support OFDMA |
| Support MU-MIMO | |
| Support Mesh Networking and beamforming | |
| Support dual frequency integration | |
| Software Data | |
| Internet access | PPPoE, DHCP, Static IP |
| IP protocol | IPv4 & IPv6 |
| Software upgrade | All-inclusive upgrade |
| Web page upgrade | |
| TR069 upgrade | |
| Working mode | Bridge Mode, Routing Mode, Relay Mode |
| Routing mode | Support static routing |
| TR069 | HTTP/HTTPS |
| Support downloading and extracting the ACS configuration file | |
| Support device configuration download | |
| Support query/configuration parameters | |
| Support remote upgrade | |
| Support remote debugging | |
| Support tour monitoring | |
| Security | Support NAT function |
| Support firewall function | |
| Support DMZ | |
| Support setting automatic DNS and manual DNS | |
| Others | Support Ping trace route tcpdump |
| Language can be customized | |
| Supports dual accounts for administrator and user management, presenting different interfaces and content. | |
| Support current configuration backup and recovery | |
| Support to export the log of device operation | |
| Network connection status | |
