SWR-4GE30W6H 1*WAN 3*LAN AX3000 WIFI6 Router
Model Number: SWR-4GE30W6H
Brand: Softel
MOQ: 1
Up to 3 Gbps combined speeds
AX3000 high performance
Support easy mesh function
01
Product Description
SWR-4GE30W6H is launched to be oriented to multi-service integration network as an optical network unit device, it configures one wan port, three 10/100/1000Mbps ports, WiFi6 (AX3000) port.
Features:
- Compliance with IEEE802.11b/g/n/ac/ax 2.4G & 5G WIFI standard
- Support web management
- Support WPS function
- Support easy mesh function
- Enable and disable your guest zone, check login credentials and reboot the system hands-free
- Support firmware and access control
- Support QoS function
- Support DMZ
- Support Multicast
Highlights:
- Wi-Fi 6 (802.11ax) Technology - Up to 3 Gbps combined speeds (574 Mbps on 2.4GHz + 2402 Mbps on 5GHz).
- AX3000 Performance - Optimized for 4K streaming, gaming, and smart home devices.
- Support easy mesh function
- 1024-QAM Modulation – 25% faster throughput than Wi-Fi 5 (802.11ac).
| Hardware Specifications | |
| Interface | 1WAN + 3GE LAN + 2.4G/5.8G WLAN（AX3000） |
| Power adapter input | 100V-240V AC，50Hz-60Hz |
| Power Supply | DC 12V/1.0A |
| Indicator light | SYS-WPS-WLAN-LAN1-LAN2-LAN3 |
| Button | Power switch Button,Reset Button,WPS Button |
| Power Consumption | ＜12W |
| Working temperature | 0℃～+40℃ |
| Environment humidity | 5% ~ 95%（non-condensing） |
| Dimension | 180mm x 133mm x 28mm（L×W×H Without antenna） |
| Net Weight | 0.28Kg |
| Ethernet Interface | |
| Wan Port | Interface type：1* RJ45 Interface parameters：10/100/1000BASE-T |
| Lan Port | Interface type：3* RJ45 Interface parameters：10/100/1000BASE-T |
| Wireless |
|
| Interface type | External 4*2T2R External antenna |
| Antenna gain | 5dBi |
| Interface maximum rate | 2.4G WLAN： 574Mbps
5.8G WLAN： 2402Mbps |
| Interface working mode | 2.4G WLAN：802.11 b/g/n/ax
5.8G WLAN：802.11 a/n/ac/ax |
