Tx-215-10mW 45~2150MHz FTTH SAT-IF Optical Transmitter
Model Number: Tx-215-10mW
Brand: Softel
MOQ: 1
45~2150MHz Wide operating frequency range
Excellent Linearity and flatness
Single-mode fiber high return loss
01
Product Description
The Tx-215-10mW optical transmitter is a high-performance device built for FTTH (Fiber to the Home) networks, making it an ideal choice in the field of fiber optic transmission due to a series of outstanding features.
It has a wide operating frequency range of 45~2150MHz, which can easily handle multiple signal transmission needs, ensuring stable signal transmission over a wide frequency range. At the same time, it has excellent linearity and flatness, effectively reducing signal distortion and ensuring the high quality of the transmitted signal.
Features:
1.Designed for FTTH(Fiber To The Home) networks
2.Wide operating frequency range:45~2150MHz
3.Excellent Linearity and flatness
4.Single-mode fiber high return loss
5.Using GaAs amplifier active devices
6.Ultra low noise technology
7.Using DFB coaxial small package laser
8.Smaller size and easier install
9.Output 13/18V、0/22KHz for LNB working
10.Using bicolor LEDs for 13/18V,0/22KHz output indication
11.Using Aluminum alloy Housing, good heat dissipation performance
|
Number |
Item |
Unit |
Description |
Remark |
|
Customer Interface |
||||
|
1 |
RF Connector |
|
F-female |
|
|
2 |
Optical Connector |
|
SC/APC |
|
|
3 |
Power Adapter |
|
DC2.1 |
|
|
Optical Parameter |
||||
|
4 |
Optical Return Loss |
dB |
≥45 |
|
|
5 |
Output Optical Wavelength |
nm |
1550 |
|
|
6 |
Output Optical Power |
mW |
10 |
10dBm |
|
7 |
Optical Fiber Type |
|
Single Mode |
|
|
RF+SAT-IF Parameter |
||||
|
8 |
Frequency Range |
MHz |
45~860 |
|
|
950~2150 |
||||
|
9 |
Flatness |
dB |
±1 |
|
|
10 |
Input Level |
dBµV |
80±5 |
RF |
|
75±10 |
SAT-IF | |||
|
11 |
Input Impedance |
Ω |
75 |
|
|
12 |
Return Loss |
dB |
≥12 |
|
|
13 |
C/N |
dB |
≥52 |
|
|
14 |
CSO |
dB |
≥65 |
|
|
15 |
CTB |
dB |
≥62 |
|
|
16 |
LNB Power supply |
V |
13/18 |
|
|
17 |
Maximum Current For LNB |
mA |
350 |
|
|
18 |
22KHz Accuracy |
KHz |
22±4 |
|
|
Other Parameter |
||||
|
19 |
Power Supply |
VDC |
12 |
|
|
20 |
Power Consumption |
W |
<3 |
|
|
21 |
Dimensions |
mm |
105x84x25 |
|
