Mini 3GE+USB2.0+WiFi6 AX1500 Wireless WIFI 6 Router
Model Number: SWR-3GE15W6
Brand: Softel
MOQ: 1
RTL CPU Chipset + Wi-Fi Chipset(2.4GHz With FEM)
Reliable WiFi Speed of up to 1.5 Gbps
OFDMA + MU-MIMO; Connect More Devices
SWR-3GE15W6(3GE+USB2.0+WiFi6 AX1500 Wireless Router) adopts WiFi6 technology which has redefined home WiFi. Experience up to 3x faster speeds, higher capacity, and reduced congestion overall compared to the previous AC WiFi5 standard. The AX1500 4-stream dual-band WiFi6 wireless router reaches speeds of up to 1.5 Gbps, for a buffer-free 4K/HD streaming and gaming experience.
The WiFi6 router lets you connect even more devices via OFDMA technology, minimizing network congestion that occurs with too many connected devices. Realtek CPU Chipset and Realtek Wi-Fi Chipset effortlessly handle all your streaming, gaming, and smart home devices. SWR-3GE15W6 uses Beamforming technology to focus WiFi signal to your devices for more reliable coverage. The SWR-3GE15W6 is easy to use and set up with Web UI.
| SWR-3GE15W6 3GE+USB2.0+WiFi6 AX1500 Wireless WIFI 6 Router | |
| Hardware Parameter | |
| Dimension | 115*115*135mm(L×W×H) |
| Net weight | 0.350KG |
| Working condition | Working temp: 0~+50°C |
| Working humidity:5~90%(non-condensing) | |
| Storing condition | Storing temp: -30~+60°C |
| Storing humidity:5~ 90% (non-condensing) | |
| Power adapter | DC 12V/1A |
| Power supply | ≤10W |
| Interface | 3*GE + WiFi6 + USB2.0 |
| Indicators | STATUS(1), RJ45(3) |
| Button | Reset, WPS |
| Interface Parameter | |
| User Interface | 3*10/100/1000Mbps auto adaptive Ethernet interface , RJ45 connectors(1*WAN, 2*LAN) |
| WLAN Interface | Compliant with IEEE802.11b/g/n/ac/ax |
| 1200 Mbps on 5GHz and 300Mbps on 2.4 GHz | |
| 2.4Ghz: 2*2, 5GHz: 2*2; 4*4dBi internal antenna | |
| Maximum number of connected devices: 32 for 2.4GHz and 32 for 5GHz | |
| USB | 1×USB 2.0 for Shared Storage/Printer |
| Function Data | |
| Management | WEB/Telnet/TR-069/Cloud Management |
| Multicast | Support IGMP v1/v2/v3 |
| Support IGMP Proxy an Snooping | |
| WAN | Maximum speed of 1Gbps |
| Wireless | Wi-Fi 6: 802.11a/n/ac/ax 5GHz & 802.11g/b/n 2.4GHz |
| WiFi Encryption: WPA/WPA2/WPA3 personal, WPS2.0 | |
| Support MU-MIMO TX/RX and MU-OFDMA TX/RX | |
| Support Beamforming | |
| Support Beamsteering | |
| Support WIFI Easy-mesh function | |
| L3/L4 | Support IPv4, IPv6 and IPv4/IPv6 dual stack |
| Support DHCP/PPPOE/Statics | |
| Support Static route,NAT | |
| Support DMZ, ALG,UPnP | |
| Support Virtual Server | |
| Support NTP (Network Time Protocol) | |
| Support DNS Client and DNS Proxy | |
| DHCP | Support DHCP Server & DHCP Relay |
| Security | Support local access control |
| Support IP address filtering | |
| Support URL filtering | |
| Support Anti-DoS attack function | |
| Support Anti-port scanning function | |
| Suppression of protocol-specific broadcast/multicast packets (e.g. DHCP, ARP, IGMP, etc.) | |
| Support Anti-Intranet ARP Attack | |
| Support Parental control function | |
