FTTH Dual Band 2GE+WiFi GPON ONU 2.4G&5G 4 Antennas
Model Number: ONT-2GE-DW
Brand: Softel
MOQ: 1
WiFi 5 Dual Band Up to 1200Mbps
Support EasyMesh and OAM/OMCI Protocol
Detect and Switch PON Mode Automatically
01
Product Description
ONT-2GE-DW (2GE+WiFi5 XPON ONT) is a cutting-edge device specially designed to meet the growing demand of fixed network operators for FTTH and triple play services. This ONT adopts a high-performance chipset (Realtek) technology solution to achieve smooth data transmission at an unprecedented speed, while supporting IEEE802.11b/g/n/ac WIFI technology and providing other layer 2/layer 3 functions. ONT supports OAM/OMCI protocol, which is very convenient to configure and manage various services on the SOFTEL OLT platform.
The accompanying ONU is known for its exceptional reliability, making it one of the easiest devices to manage and maintain. Provide quality of service (QoS) guarantees for various services such as video streaming and large downloads, ensuring that users always get the best service quality that meets international technical standards such as China Telecom CTC2.1/3.0 and IEEE802. 3ah, ITU-T G.984, etc. In short, this ONT/ONU device is the perfect choice for fixed network operators looking to provide the best FTTH and triple play services to their customers.
| ONT-2GE-DW Dual Band 2GE+WiFi GPON ONU 2.4G&5G 4 Antennas | |
| Hardware Parameter | |
| Dimension | 178mm×120mm×30m(L×W×H) |
| Net weight | 0.31Kg |
| Operating Condition | Operating temp: 0 ~ +55°C |
| Operating humidity: 10 ~ 90% (non-condensed) | |
| Storing Condition | Storing Temp: -30 ~ +60°C |
| Storing humidity: 10 ~ 90% (non-condensed) | |
| Power Adapter | DC 12V,1.0A, External AC-DC power adaptor |
| Power Supply | ≤12W |
| Interface | 2GE+WiFi5 |
| Indicators | PWR, PON, LOS, WAN, LAN1, LAN2, 2.4G, 5G |
| Interface Fetures | |
| PON interface | 1XPON port(EPON PX20+ and GPON Class B+) |
| SC single mode, SC/UPC connector | |
| TX optical power: 0～+4dBm | |
| RX sensitivity: -27dBm | |
| Overload optical power: -3dBm(EPON) or -8dBm (GPON) | |
| Transmission distance: 20KM | |
| Wavelength: TX 1310nm, RX1490nm | |
| WiFi interface | Compliant with IEEE802.11b/g/n/ac |
| WiFi:2.4GHz 2×2, 5.8GHz 2×2, 5dBi antenna, rate up to 1.167Gbps,Multiple SSID | |
| TX power: 2.4GHz: 23dBm; 5GHz: 24dBm | |
| RX power: 2.4GHz: HT40-MCS7 -72dBm; 5GHz: VHT80 MCS9 <-62dBm | |
| User interface | 2×GE, Auto-negotiation,RJ45 ports |
| Functionl Parameters | |
| O&M | OAM/OMCI,Telnet,WEB,TR069 |
| Support full management of HGU functions by VSOL OLT | |
| Connect Mode | Support bridge, router & bridge/router mixed mode |
| QoS | Support 4 queues |
| Support SP, WRR, 802.1P and DSCP | |
| Data Service Functions | • Full speed non-blocking switching |
| • 2K MAC address table | |
| • 64 full range VLAN ID | |
| • Support VLAN tag, untag, transparent, trunk, translation mode | |
| • Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc | |
| • Support auto polarity detection of Ethernet ports (AUTO MDIX) | |
| • Support IGMP v1/v2/v3 snooping/proxy and MLD v1/v2 snooping/proxy | |
| Wireless | Integrated 802.11b/g/n/ac |
| • Authentication:WEP/WAP-PSK(TKIP)/ WAP2-PSK(AES) | |
| • Modulation type:DSSS,CCK and OFDM | |
| • Encoding scheme:BPSK,QPSK,16QAM and 64QAM | |
| Easymesh | |
| VoIP | SIP and IMS SIP |
| G.711a/G.711u/G.722/G.729 Codec | |
| Echo cancellation,VAD/CNG,DTMF Relay | |
| T.30/T.38 FAX | |
| Caller Identification/Call Waiting/Call Forwarding/Call Transfer/Call Hold/3-way Conference | |
| Line testing according to GR-909 | |
| L3 | IPv4, IPv6 and IPv4/IPv6 dual stack |
| DHCP/PPPOE/Static | |
| Static route, DHCP Server | |
| NAT/DMZ/DDNS/Virtual Server | |
| Security | Support Firewall |
| Support Mac filter Based on MAC or URL | |
| Support ACL | |
ONT-2GE-DW FTTH Dual Band 2GE+WiFi GPON ONU Datasheet.PDF
