SR1602AF CATV FTTH Fiber Optic Node with SC/APC Optical Connector
Model Number: SR1602AF
Brand: Softel
MOQ: 1
Optical AGC range is -5 ~ 15dBm
47~1000MHz full coverage
Adopts GaAs module as RF amplifying module
01
Product Description
Introduction
SR1602AF FTTH optical node is specifically designed for CATV FTTH network. Its main feature is low powerconsumption, optical input -5~-15dBm(AGC range can be customizable), optical constant level output, smallVolume and high reliability. Adopting aluminum casing, compact structure and external modular power supplymake the installation and debugging very convenient. It is an ideal product to build FTTH CATV network.
Performance Characteristic
- Aluminum casing with good heat dispersion.
- Adopts GaAs module as RF amplifying module, the optical receiving range for digital signal can reach -18dBm.
- AGC control range -5~-15dBm, output level keeps unchanged.
- Low consumption design and total consumption ≤3w, high reliable switching power supply.
- Supply with optical inspection circuit.
- SC/APC or FC/APC optical connector
- Realize the 8V input port feeding way of power supply.
| Item | Unit | Paramter | Remark |
| Optical wavelength | (nm) | 1100~ 1600&1550 | |
| Optical input range | (dBm) | 0~-18 | |
| Output return loss | (dB) | ≥45 | |
| Bandwidth (MHz) | MHz | 47~862&1000MHz | |
| Flatness (dB) | dB | ±1 | |
| RF output level | (dBuv) | ≥80dBuv（1 port） ≥76dBuv（2ports） | Pin: -5~-15dBm |
| AGC range | (dBm) | -3~-12 | |
| Output return loss | (dB) | ≥14 | Pin: -5~-15dBm |
| Output impendance | (Ω) | 75 | |
| CNR (dB) | dB | ≥51 | 47-1006MHz |
| CTB (dB) | dB | ≥65 | |
| CSO (dB) | dB | ≥62 | |
| Power supply (V) | V | AC110V or AC220V or customized | |
| Power consumption | W | ≤3 | |
| Operating temperature | (℃) | -20~+60 | |
| Dimension | mm | 105*67*24 |
